- Brief introduction
- Product parameters
- Product picture
Major Features
1)SpO2 value display
2)Pulse rate value display, bar graph display
3)Pulse waveform display
4)The display mode can be changed
5)Screen brightness can be changed
6)Display format can be saved after power off
Main performance
1) Display Mode:Color display
2) Screen Resolution:128*64
3) SpO2 Measuring Range:0%~100%, (the resolution is 1%).
Accuracy:70%~99%:±1% ,Below 70% unspecified.
4) PR Measuring Range:30bpm~240bpm, (the resolution is 1bpm)
Accuracy:±2bpm or ±2% (select larger)
5) Measurement Performance in Weak Filling Condition:SpO2 and pulse rate can be shown correctly when pulse-filling ratio is 0.4%. SpO2 error is ±4%, pulse rate error is ±2 bpm or ±2% (select larger).
6) Resistance to surrounding light: The deviation between the value measured in the condition of man-made light or indoor natural light and that of darkroom is less than ±1%
